Opek Technologies

★ 1.0 (1 review)ยท40 productsยท$10.95 โ€“ $154.95
Shop by type
Truck or Treat โ€” SPEND MORE, GET MORE โ€” Unlock Discounts and Free Gifts! You may not get candy, but you do get to fill up your bucket with something even betterโ€”no costume required. ยท ends Oct 31 Code SPOOKY26 See details
40 products ยท3 sold out ยท8 discontinued ↓
HVT400B80M 80M/ 40M / 20M / 15M / 10M / 6M / 2M / 70cm Meter Ant
Sale
Opek Technologies HVT-400B
Opek HVT-400B 8 Band HF/VHF/
  • Multiband: Covers 80 / 40 / 20 / 15 / 10 / 6 / 2 meter and 70cm
  • UHF Connection
  • Retractable Telescopic Whip for Improved Tuning
$79.95 $89.95Save $10.00
In Stock
Currently unavailable ยท 3

Opek Technologies questions

Is there continuity between the outer barrel on the SO-239 and the inside threading on the NMO?

Yes, verified 9/16/2024 that the SO-239 outer barrel has continuity to the bottom NMO threaded side. The center conductor has continuity as well.

How do I check my SWR using this meter?
From OPEK's Manual:

1. Turn the transmitter of and disconnect the antenna coaxial cable at the output.

2. Connect the SWR-3 โ€œTRANSโ€ connector to the transmitter output, and โ€œANTโ€ to antenna connector. As short cable equipped with male connectors on both ends will be required between the transmitter and the meter.

3. Set the slide switch to โ€œSWRโ€ and โ€œFWDโ€. Rotate the โ€œSET & FS ADJโ€ counterclockwise to near minimum position.

4. Turn the transmitter on, rotate the โ€œSET & FS ADJโ€ for full scale, โ€œSETโ€ position on meter.

5. Next, set the slide switch FWD/REF to โ€œREFโ€ and read the meter scale. The meter will give the SWR reading directly.

6. A 1:1 ratio is the ideal match. Adjustments on the antenna system should be made so that the SWR is as low as possible. A SWR of 2.0 is considered satisfactory, taking into account the line losses and slight mismatching. The operator is referred to the numerous articles in radio magazines and books dealing with various proper matching methods of different types of antennas. NEVER attempt to adjust the set to the antenna.

7. The power required for the SWR bridge operation is dependent on the frequency; about 25 watts of 3.5 MHz, 15 watts at 7 MHz, and proportionately lower power at higher frequencies. If the transmitter power is not sufficient and a full meter swing cannot be achieved, adjust the antenna system for the lowest possible swing at the โ€œREFโ€ position of the slide switch.
How do I use the meter to read RF Power
From OPEK's Manual:

1. Connect the SWR-3 โ€œTRANSโ€ connector to the transmitter output, and โ€œANTโ€ to antenna connector.

2. Set the slide switch (SWR, PWR) at POWER position, and set the range slide switch (FWD, REF) to either 10 watts or 100 watts position, whichever is suitable.

3. When the transmitter switch is on, the meter needle will deflect. Read the amount of deflection on the top scale. If the range switch had been set to the 100 watt range, the value is multiplied by 10.

4. For accurate power reading the SWR-3 should be used in circuits having SWR value of up to 1.5. The meter accurately will decrease if the SWR value exceeds 1.5.

5. Always have the meter switched off when removing this meter from the circuit.

6. NEVER disconnect the โ€œANTโ€ connector when transmitting. The abnormal voltage generated may damage the transmitter.
How do I use the SWR-3 as a field strength indicator?
This instrument is designed so that comparative RF field strength can be determined. A pair of diodes has been inserted in the circuit to rectify the RF energy picked up by the small antenna. Remove the instrument from the transmitter output circuit and restore the former transmitter antenna connections.

1. Set the slide switch to โ€œSWRโ€ and โ€œFWDโ€

2. Fasten the bar antenna to the stud on the side of the case.

3. Bring the SWR-3 in the vicinity of the transmitter of antenna system with the transmitter in operation. Be careful that the pickup antenna does not come in contact with any metallic portion of the transmitter or antenna.

4. The adjusting knob is rotated to obtain a convenient reading on the meter.

5. After the aforementioned steps have been taken, any adjustments performed on the transmitter or antenna will be reflected by an increase of decrease in the meter reading.
