Alinco DM-30T 20-30A Switching AC to DC Power Supply with Variable Voltage and Large Display

30 Amp Peak Power, Large Meter Displays Voltage & Current. Front mounted Anderson Powerpole® connectors

  • 20A Constant Power Supply (30A max)
  • 9-15V Variable Voltage
  • Noise offset removes unwanted RF interference
  • Large Display
  • Compact Size only 6" wide x 3" tall

844-925-2688

Call to order DM30T

Item #: DM30T

In Stock
Sale $129.95
$199.95Save $70.00

Select Your Upgrades View all

Anderson Type DC Mini Connectors DC1

Alinco DM30T Overview

Alinco high quality DC power supply, rated up to 30A and has adjustable, variable voltage from 9V up to 15V. The large easy to read Volt and AMP display is clear and concise, and all of this is achieved in a remarkably small chassis that is only 6 inches wide and 3 inches tall! Large power connection on the rear of the power supply are used for any high current application, on the front of the unit there is a pair of compact Anderson power poles. Additionally, the The Noise Offset Circuit moves unwanted switching noise to another frequency. Keeping everything cool is achieved with forced air cooling, keeping everything cool under heavy loads.

Alinco DM30T Features

  • Input Voltage220VAC 50/60Hz (DM-30E) 120VAC 50/60Hz (DM-30T)
  • Output voltage13.8V DC (rated) variable 9~15V DC
  • Output current20A continuous at 13.8VDC, 30A max (50% duty cycle, 1min. interval)
  • Output voltage regulationLess than 2%
  • Ripple voltageLess than 80mVp-p
  • ProtectionAutomatic current shut down over 30A, Temperature protection circuit
  • Fuse5A (DM-30E) / 8A(DM-30T)
  • DimensionsWxHxD 155 x 75 x 205 mm or 6.10 x 2.80 x 8.07 inches (T)
  • WeightApprox. 1.6kg or 3.53 lb with AC cord
