Operating Frequencies | |
---|---|
10.500 – 10.550 GHz (X-Band) | |
23.950 – 24.285 GHz (K-Band) | |
33.400 – 36.000 GHz (Ka-Band) | |
830 – 945 nanometers (Laser) | |
K-Band Selectivity | Scans specific K-Band frequency ranges |
K Narrow | 24.080-24.200 GHz |
K Wide (DEFAULT SETTING) | 24.026-24.285 GHz |
K Extended (Scans specific K-Band frequency ranges) | 23.950-24.285 GHz |
Ka-Band Selectivity | Scans 100 GHz above/below the most important frequencies |
Ka Narrow | 33.7-33.9 GHz / 34.6-34.8 GHz / 35.4-35.6 GHz |
Ka Wide (DEFAULT SETTING) | 33.4-36.00 GHz |
Power Requirements | 10.05 – 16.0 Volts DC negative ground | 185 mA typical standby |
Dimensions | 4.50 in. L x 3.50 in. W x 1.45 in. H |
